YUKEN Series Relief Valve S-BSG-06-2B3B-D24-N1-51

Model:
S-BSG-06-2B3B-D24-N1-51
Max Pressure:
25MPa
Flow Capacity:
200L/min
Weight:
Description:
Low Noise Type Solenoid Controlled Relief Valves . The low-noise solenoid controlled relief valve is a combination of a low-noise type pilot operated relief valve and a solenoid operated directional valve. It is used for no-load pump operation by using electri

Product details description

Low Noise Type Solenoid Controlled Relief Valves .          The low-noise solenoid controlled relief valve is a combination of a low-noise type pilot operated relief valve and a solenoid operated directional valve. It is used for no-load pump operation by using electric signals or, together with a remote control relief valve, for two or three pressure control of the hydraulic system.

.          The low-noise solenoid controlled relief valve is a combination of a low-noise type pilot operated relief valve and a solenoid operated directional valve. It is used for no-load pump operation by using electric signals or, together with a remote control relief valve, for two or three pressure control of the hydraulic system.
