Product details description

     As a high-pressure vane pump,Its working pressure can reach up to 21MPa at most, making it suitable for high-pressure scenarios in construction machinery. ‌
    The floating side plate structure is adopted to automatically compensate for the end face clearance, maintaining high efficiency under high pressure. ‌
    Blade structure: 10-blade design, combined with hydraulic balance mother and child blades, to enhance pressure stability. ‌
    Side plate material: Bimetallic material, enhancing anti-seizing performance and extending service life. ‌
    Multi-displacement and multi-shaft extension configurations are available to meet the demands of complex working conditions. ‌
