Product details description

The double-vane pump features high working pressure, low noise and long service life.
High working pressure ‌ : Supports 210 bar (3000 psi) working pressure, with volumetric efficiency exceeding 90%, suitable for high-pressure hydraulic systems.
Low-noise design ‌ : The mother and child blade mechanism and 12-blade structure reduce flow pulsation, with noise levels as low as 62 dB(A), enhancing operational comfort. ‌
Blade design ‌ : A double-blade structure is adopted. The top of the blade is sealed and closely attached to the inner surface of the stator, and the bottom oil chamber is connected to the outlet to achieve pressure balance and reduce wear.
Youdaoplaceholder0 Hydraulic balance ‌ : The radial load of the shaft and bearings is balanced through hydraulic design to extend the service life.
